CALLEJON L01175 - CEILING RECESSED LIGHT
BASE: L01175CALLEJON lighting solution with professional specifications
Specifications at a Glance
7W
Power
856LM
Lumen Output
2700K3000K4000K6000K
Available Colour Temperatures
CRI 80
Colour Rendering Index
IP20
Protection Rating
10° / 20° / 30°
Beam Angle
250mA
Input
Ø85mm
Cutout Size
BlackWhite
Available Finishes
DALINon-DimmableTriac
Dimming Options
recessed-downlight, surface-mounted
Mounting Type
Certifications & Compliance
CE
RoHS
IP20
5 Year Warranty
CONFIGURE YOUR PRODUCT
Select your preferred specifications to generate the exact order code.
CRI 80
Generated Order Code
L01175.927.03.30
Available
Total Available Configurations: 18
Your Configuration
Color Temperature
2700K
Beam Angle
10°
Body Finish
Black
Cri
CRI 80
Dimming
⚡
DALINeed help configuring? Contact our sales team for assistance.
AVAILABLE CONFIGURATIONS
18 standard configurations ready for immediate order
Smart PDF Generation: Use the configurator above to select your specific options (light type, CCT, finish, length), then click "Download Datasheet" to generate a custom PDF for your exact configuration.
L01175.940.03.30
CCT:
4000K
Power:7W
Lumen:856LM
Beam:
30°
Finish:
CRI 90IP20Black
L01175.940.03.20
CCT:
4000K
Power:7W
Lumen:856LM
Beam:
20°
Finish:
CRI 90IP20Black
L01175.940.03.10
CCT:
4000K
Power:7W
Lumen:856LM
Beam:
10°
Finish:
CRI 90IP20Black
L01175.930.03.30
CCT:
3000K
Power:7W
Lumen:856LM
Beam:
30°
Finish:
CRI 90IP20Black
L01175.930.03.20
CCT:
3000K
Power:7W
Lumen:856LM
Beam:
20°
Finish:
CRI 90IP20Black
L01175.930.03.10
CCT:
3000K
Power:7W
Lumen:856LM
Beam:
10°
Finish:
CRI 90IP20Black
Need Custom Options?
Looking for different CCT, finish, beam angle, or other specifications? Our team can help configure the perfect solution for your project.
Questions about configurations? Contact our sales team for technical assistance.
Product Information
- Category:
- CEILING RECESSED LIGHT
- Series:
- CALLEJON
- Family:
- CALLEJON
Applications
Office
Jewellery Display
